Full Machine Lineup
Table of Contents
As of 11/28/23 our metal cabinets are now only being made with stainless steel. Our website is currently being updated. For any questions, please call 828-202-5563.
Vapor Honing Machines
Micro Vapor Hone
| Workspace: 17"W x 13"D x 13"H | Footprint: 20"W x 14"D x 22"H |
| HDPE Cabinet | No Power Needed |
| 10-15 CFM | 60-70 PSI |
| 2 Gallons of Water | 5 lbs. of Abrasive |
| Standard Regulator | No Assembly Required |
VH700
| Workspace: 24"W x 18"D x 20"H | Benchtop or Stand Alone |
| HDPE Cabinet | 110V |
| 20-30 CFM | 60-100 PSI |
| Fill To Top Drain Valve | 12 lbs. of Abrasive |
| LED Flood Light | Standard Regulator |
Weekend Warrior
| Workspace: 33"W x 30"D x 28"H | Footprint: 33"W x 30"D x 68"H |
| HDPE Cabinet | 110V |
| 20-30 CFM | 60-100 PSI |
| 18 Gallons of Water | 25 lbs. of Abrasive |
| Foot Pedal Control | LED Flood Light |
VH800 Base
| Workspace: 33"W x 30"D x 28"H | Footprint: 36"W x 35"D x 68"H |
| HDPE Cabinet | 110V or (220V +$300) |
| 20-30 CFM | 60-100 PSI |
| 18 Gallons of Water | 25 lbs. of Abrasive |
| Automatic Overflow Valve | 2' LED Light Bar |
VH800 Fully Loaded
| Workspace: 33"W x 30"D x 28"H | Footprint: 36"W x 35"D x 68"H |
| HDPE Cabinet | 110V or (220V +$300) |
| 20-30 CFM | 60-100 PSI |
| 18 Gallons of Water | 25 lbs. of Abrasive |
| Wiper Included | Precision Regulator |
VH800 Pro
| Workspace: 33"W x 30"D x 28"H | Footprint: 36"W x 35"D x 68"H |
| SS or CS Cabinet | 110V or (220V +$300) |
| 20-30 CFM | 60-100 PSI |
| 18 Gallons of Water | 25 lbs. of Abrasive |
| Wiper Included | Precision Regulator |
VH900
| Workspace: 36"W x 24"D x 30"H | Footprint: 40"W x 36"D x 68"H |
| SS or CS Cabinet | 110V or (220V +$300) |
| 20-30 CFM | 60-100 PSI |
| 24 Gallons of Water | 34 lbs. of Abrasive |
| Front Load Door | Wiper Included |
VH3630
| Workspace: 36"W x 30"D x 38"H | Footprint: 40"W x 40"D x 84"H |
| SS or CS Cabinet | 110V |
| 20-30 CFM | 60-100 PSI |
| 22.5 Gallons of Water | 32 lbs. of Abrasive |
| Wiper Included | 2' LED Lightbar |
VH1000
| Workspace: 36"W x 30"D x 38"H | Footprint: 40"W x 40"D x 84"H |
| SS or CS Cabinet | 110V or (220V +$300) |
| 20-30 CFM | 60-100 PSI |
| 22.5 Gallons of Water | 32 lbs. of Abrasives |
| Automatic Overflow | Wiper Included |
VH1000 Heavy Duty
| Workspace: 36"W x 30"D x 38"H | Footprint: 40"W x 60"D x 84"H |
| SS Only | 208V 3P |
| 30 CFM | 60-120 PSI |
| 25 Gallons of Water | 35 lbs. of Abrasive |
| Custom Built Pump | 2 Stage Filtration (Opt.) |
VH2000
| Workspace: 40"W x 40"D x 40"H | Footprint: 46"W x 44"D x 84"H |
| SS or CS Cabinet | 110V or (220V +$300) |
| 20-30 CFM | 60-100 PSI |
| 25 Gallons of Water | 35 lbs. of Abrasive |
| Wiper Included | Automatic Overflow |
VH3500
| Workspace: 60"W x 30"D x 38"H | Footprint: 75"W x 38"D x 84"H |
| SS or CS Cabinet | 110V or (220V +$300) |
| 20-30 CFM | 60-100 PSI |
| 29 Gallons of Water | 41 lbs. of Abrasive |
| Dual Wipers Included | Large Front Load Design |
VH4000
| Workspace: 60"W x 48"D x 38"H | Footprint: 60"W x 50"D x 84"H |
| SS or CS Cabinet | 110V or (220V +$300) |
| 20-30 CFM | 60-100 PSI |
| 30 Gallons of Water | 42 lbs. of Abrasive |
| Dual Side Load | Opt. Dual Man Station |
VH4000 Heavy Duty
| Workspace: 60"W x 48"D x 38"H | Footprint: 60"W x 50"D x 84"H |
| SS Only | 220V 1P or 480V 3P |
| 20-30 CFM | 60-120 PSI |
| 30 Gallons of Water | 42 lbs. of Abrasives |
| Custom Built Pump | Dual Side Load |
Mobile Vapor Honing Unit
| SS Only | Blast Anywhere |
| Great for Outdoors | 110V Single Phase |
| 20 CFM | 100-130 PSI |
| 18 Gallons of Water | 25 lbs. of Abrasives |
| Handheld Blast Wand | Standard Regulator |
VH900 Tumbler
| Workspace: 36"W x 24"D x 30"H | Footprint: 40"W x 36"D x 68"H |
| SS Only | 220V Single Phase |
| 20-30 CFM | 60-100 PSI |
| 24 Gallons of Water | 34 lbs. of Abrasive |
| Speed Controlled Basket | Hands Free Blasting |
Gladiator
| Workspace: 36"W x 30"D x 30"H | Footprint: 64"W x 58"D x 83"H |
| SS Only | 208V 3P |
| 40 CFM | 60-100 PSI |
| 28.5 Gallons of Water | 40 lbs. of Abrasive |
| Positionable Turntable | Linear Blast Movement |
| Easily Programmable | Fully Automated |
The Robo-IQ
If you are ready to blast into the future of wet blasting, this is the machine to do so with.
For more information, please click the link above to view the complete Robo-IQ page
Automated Indexing Station
| Workspace: 60"W x 60"D x 48"H | Front Loading Work Station |
| SS - Industrial/Commercial | 208V or (480V +$300) |
| Servo Driven Motion System | 45 lbs. of Abrasives |
| 150 CFM | 100-150 PSI |
| 75 Gallons of Water | Large HMI User Interface |
| Closed Loop Rinsing Sedimentation Tank | Fully Automated |
The Platform
| Workspace: 11'W x 11'D x 48"H | Footprint: 40"W x 36"D x 68"H |
| SS - Large Industrial/ Commercial | 220V |
| 185 CFM | 150 lbs. of Media |
| No Dust | No Heat |
| Optional Setup/Training | 80-100 PSI |
Call For More Information About The Platform
828-202-5563
Parts Washing Equipment
Hydro Blast
| Workspace: 33"W x 30"D x 28"H | Footprint: 36"W x 35"D x 68"H |
| HDPE - Parts Washer | 220V |
| Immersion Heater | NO ABRASIVES |
| Aqueous Base Det. | Internal Dryer Hose |
| 18 Gallons of Water | Wiper Included |
VH1000 Hydro Blast
| Workspace: 36"W x 30"D x 38"H | NO ABRASIVES |
| SS Industrial - Parts Washer | 220V Single Phase |
| High Volume Pressure Pump | 30 Gallons of Water |
| 1200 PSI at The Gun | Internal Dryer Hose |
| Foot Pedal Control | Wiper Included |
VH1000 Hydro Blast Max
| Workspace: 36"W x 30"D x 38"H | NO ABRASIVES |
| SS Industrial - Parts Washer | 220V 1P or 480V 3P |
| High Volume Pressure Pump | 4000 PSI |
| Immersion Heater | Internal Dryer Hose |
| Foot Pedal Control | Wiper Included |
Auto Parts Washer
| Workspace: 16"W x 16"D x 30"H | NO ABRASIVES |
| Mild Steel Parts Washer | 110V Single Phase |
| High Volume Pressure Pump | 8 Gallons of Water |
| Automatic Wash | Fully Assembled |
Medium Auto Parts Washer
| Workspace: 30"W x 30"D x 60"H | NO ABRASIVES |
| Mild Steel Parts Washer | 110V Single Phase |
| High Volume Pressure Pump | 16 Gallons of Water |
| Automatic Wash | Fully Assembled |
Large Auto Parts Washer
| Workspace: 42"W x 42"D x 84"H | NO ABRASIVES |
| Mild Steel Parts Washer | 110V Single Phase |
| High Volume Pressure Pump | 24 Gallons of Water |
| Automatic Wash | Fully Assembled |
Vapor Honing Dry Blast
VH800 Pro Dry Blast
| Workspace: 33"W x 30"D x 28"H | Footprint: 36"W x 35"D x 68"H |
| CS - Industrial | 110V |
| Foot Pedal Control | 25 lbs. of Abrasives |
| 20-30 CFM | 60-100 PSI |
| No Water | Standard Regulator |
VH900 Dry Blast
| Workspace: 36"W x 24"D x 30"H | Footprint: 40"W x 36"D x 68"H |
| 110V | Foot Pedal Control |
| 35 lbs. of Abrasives | 20-30 CFM |
| 60-100 PSI | No Water |
| Standard Regulator | CS - Industrial |
VH1000 Dry Blast
| Workspace: 36"W x 30"D x 38"H | Footprint: 40"W x 40"D x 84"H |
| 110V | Foot Pedal Control |
| 32 lbs. of Abrasives | 20-30 CFM |
| 60-100 PSI | No Water |
| Standard Regulator | CS - Industrial |
VH2000 Dry Blast
| Workspace: 40"W x 40"D x 40"H | Footprint: 46"W x 44"D x 84"H |
| 110V | Foot Pedal Control |
| 35 lbs. of Abrasives | 20-30 CFM |
| 60-100 PSI | No Water |
| Standard Regulator | CS - Industrial |
VH3500 Dry Blast
| Workspace: 60″ W x 30″ D x 38″ H | Footprint: 75"W x 38"D x 84"H |
| 110V | Foot Pedal Control |
| 41 lbs. of Abrasives | 20-30 CFM |
| 60-100 PSI | No Water |
| Standard Regulator | CS - Industrial |
VH4000 Dry Blast
| Footprint: 60"W x 50"D x 84"H | CS - Industrial |
| 110V | Foot Pedal Control |
| 42 lbs. of Abrasives | 20-30 CFM |
| 60-100 PSI | No Water |
| Standard Regulator | CS - Industrial |
Abbreviation Key:
- HDPE – High Density Polyethylene
- SS – Stainless Steel
- AL – Aluminum
- CS – Carbon Steel
- OP – Open Loop (Requires water hookup and a drain for rinsing)
- CL – Closed Loop (Recycles the water for rinsing)
- FL – Fully Loaded ( Closed Loop w/Bells and whistles)
- Base – Open loop w/minimal features
- WW – Weekend Warrior
Optional Add On
| Add On | Price | Machine |
| Locking Caster Kit | $100.00 | HDPE Units |
| Protective Blasting Mat | $50.00 | All Units |
| Blasting Gun Mount | $250.00 | WW + |
| SS Angular Rods | $100.00 | WW + |
| Rubber Lined Walls | $700.00 | WW,VH800 Series,900 Series |
| Rubber Lined Walls | $1000.00 | 1000 Series |
| Rubber Lined Walls | $1500.00 | 2000 Series |
| Rubber Lined Walls | $1750.00 | 3500 Series |
| Rubber Lined Walls | $2500 | 4000 Series |
| SS/AL/CS Machine Casters | $650.00 | All Metal |
| Abrasive Density Meter | $1,000.00 | VH750 + |
| Immersion Heater | $375.00 | VH750 + |
| 20" Turntable | $999.99 | HDPE, VH750 |
| 22" Turntable | $1,099.99 | HDPE, VH750 |
| 24" Turntable | $1,199.99 | HDPE, VH750 |
| 26" Turntable | $1,299.99 | VH1000, VH3500 |
| 30" Turntable | $1,499.99 | VH1000, VH3500 |
| 40" Turntable | $1,000.00 | VH4000 |
| Track & Cart System SS ONLY | $5,500.00 | VH1000 |
| Track & Cart System SS ONLY | $6,500.00 | VH4000 |
| Guillotine Doors SS ONLY | $11,000 | VH1000 |
| Guillotine Doors SS ONLY | $12,000 | VH4000 |
| Automated Tumble Basket | $3,500.00 | VH900 ONLY |
Modifications or add-ons not normally available, will be subject to a $350 custom charge
To see videos of the machines in action, please visit our YouTube channel
Discontinued Equipment
Bench Top Vapor Hone 450
| Workspace: 20"W x 13"D x 10"H | Footprint: 20"W x 15"D x 30"H |
| SS - Research and Development | 110V ONLY |
| Foot Pedal Control | 10 lbs. of Abrasives |
| 20-30 CFM | 80-90 PSI |
| 8 Gallons of Water | Standard Regulator |
Bench Top Vapor Hone 650
| Workspace: 25"W x 25"D x 23"H | Footprint: 25"W x 25"D x 48"H |
| SS - Samll Spaces | 110V or (220V +$300) |
| (1x) 2' LED Lightbar | 13 lbs. of Abrasives |
| 20-30 CFM | 80-90 PSI |
| 9.5 Gallons of Water | Standard Regulator |
Vapor Hone Ergo 750
| Workspace: 30"W x 25"D x 24"H | Footprint: 30"W x 25"D x 68"H |
| SS - industrial | 110V or (220V +$300) |
| Foot Pedal Control | 18 lbs. of Abrasives |
| 20-30 CFM | 60-100 PSI |
| 13 Gallons of Water | Precision Regulator |
Bare Essential Weekend Warrior
| Workspace: 33"W x 30"D x 28"H | Footprint: 33"W x 30"D x 68"H |
| HDPE - Hobbyist | 110V ONLY |
| 18 Gallons of Water | 25 lbs. of Abrasives |
| 20-30 CFM | 60-100 PSI |
| NO FOOT PEDAL | NO WINDOW RINSE |
Weekend Warrior Pro
| Workspace: 33"W x 30"D x 28"H | Footprint: 33"W x 30"D x 68"H |
| CS Cabinet - Hobbyist | 110V ONLY |
| Open Loop | 25 lbs. of Abrasives |
| 20-30 CFM | 60-100 PSI |
| 18 Gallons of Water | High Volume Slurry Pump |
VH800 Base Pro
| Workspace: 33"W x 30"D x 28"H | Footprint: 36"W x 35"D x 68"H |
| CS Cabinet - Light Industrial | 110V or (220V +$300) |
| Open Loop | 25 lbs. of Abrasives |
| 20-30 CFM | 60-100 PSI |
| 18 Gallons of Water | Standard Plastic Pump Impeller |
VH1200 OP
| Workspace: 40"W x 40"D x 40"H | Footprint: 46"W x 44"D x 84"H |
| HDPE - Light Industrial | 110V ONLY |
| 2' LED Lightbar | 35 lbs. of Abrasives |
| 20-30 CFM | 60-100 PSI |
| 25 Gallons of Water | Standard Regulator |
